246 Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide
8 :BUS<n> Commands
Introduction to
:BUS<n>
Commands
<n> ::= {1 | 2}
The BUS subsystem commands control the viewing, labeling, and digital channel
makeup of two possible buses.
Reporting the Setup
Use :BUS<n>? to query setup information for the BUS subsystem.
Return Format
The following is a sample response from the :BUS1? query. In this case, the query
was issued following a *RST command.
:BUS1:DISP 0;LAB "BUS1";MASK +255
:BUS<n>:LABel
<string> (see
page 252)
:BUS<n>:LABel? (see
page 252)
<string> ::= quoted ASCII string
up to 10 characters
<n> ::= 1 or 2; an integer in NR1
format
:BUS<n>:MASK <mask>
(see page 253)
:BUS<n>:MASK? (see
page 253)
<mask> ::= 32-bit integer in
decimal, <nondecimal>, or
<string>
<nondecimal> ::= #Hnn...n where n
::= {0,..,9 | A,..,F} for
hexadecimal
<nondecimal> ::= #Bnn...n where n
::= {0 | 1} for binary
<string> ::= "0xnn...n" where n
::= {0,..,9 | A,..,F} for
hexadecimal
<n> ::= 1 or 2; an integer in NR1
format
Table 86 :BUS<n> Commands Summary (continued)
Command Query Options and Query Returns
NOTE
These commands are only valid for the MSO models.
