266 Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide
10 :CHANnel<n> Commands
:CHANnel<n>:PROBe:HEA
D[:TYPE] <head_param>
(see page 276)
:CHANnel<n>:PROBe:HEA
D[:TYPE]? (see
page 276)
<head_param> ::= {SEND0 | SEND6 |
SEND12 | SEND20 | DIFF0 | DIFF6 |
DIFF12 | DIFF20 | NONE}
<n> ::= 1 to (# analog channels)
in NR1 format
n/a :CHANnel<n>:PROBe:ID?
(see page 277)
<probe id> ::= unquoted ASCII
string up to 11 characters
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:PROBe:MMO
Del <value> (see
page 278)
:CHANnel<n>:PROBe:MMO
Del? (see page 278)
<value> ::= {P5205 | P5210 |
P6205 | P6241 | P6243 | P6245 |
P6246 | P6247 | P6248 | P6249 |
P6250 | P6251 | P670X | P671X |
TCP202}
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:PROBe:SKE
W <skew_value> (see
page 279)
:CHANnel<n>:PROBe:SKE
W? (see page 279)
<skew_value> ::= -100 ns to +100
ns in NR3 format
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:PROBe:STY
Pe <signal type> (see
page 280)
:CHANnel<n>:PROBe:STY
Pe? (see page 280)
<signal type> ::= {DIFFerential |
SINGle}
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:PROTectio
n (see page 281)
:CHANnel<n>:PROTectio
n? (see page 281)
{NORM | TRIP}
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:RANGe
<range>[suffix] (see
page 282)
:CHANnel<n>:RANGe?
(see page 282)
<range> ::= Vertical full-scale
range value in NR3 format
[suffix] ::= {V | mV}
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:SCALe
<scale>[suffix] (see
page 283)
:CHANnel<n>:SCALe?
(see page 283)
<scale> ::= Vertical units per
division value in NR3 format
[suffix] ::= {V | mV}
<n> ::= 1 to (# analog channels)
in NR1 format
Table 88 :CHANnel<n> Commands Summary (continued)
Command Query Options and Query Returns
