444 Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide
22 :MEASure Commands
:MEASure:BWIDth
[<source>] (see
page 463)
:MEASure:BWIDth?
[<source>] (see
page 463)
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= burst width in
seconds, NR3 format
:MEASure:CLEar (see
page 464)
n/a n/a
:MEASure:COUNter
[<source>] (see
page 465)
:MEASure:COUNter?
[<source>] (see
page 465)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> | EXTernal} for MSO
models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<return_value> ::= counter
frequency in Hertz in NR3 format
:MEASure:DEFine
DELay, <delay spec>
(see page 467)
:MEASure:DEFine?
DELay (see page 468)
<delay spec> ::=
<edge_spec1>,<edge_spec2>
edge_spec1 ::=
[<slope>]<occurrence>
edge_spec2 ::=
[<slope>]<occurrence>
<slope> ::= {+ | -}
<occurrence> ::= integer
:MEASure:DEFine
THResholds,
<threshold spec> (see
page 467)
:MEASure:DEFine?
THResholds (see
page 468)
<threshold spec> ::= {STANdard} |
{<threshold mode>,<upper>,
<middle>,<lower>}
<threshold mode> ::= {PERCent |
ABSolute}
Table 100 :MEASure Commands Summary (continued)
Command Query Options and Query Returns
