446 Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide
22 :MEASure Commands
:MEASure:DUAL:VPP
[<source1>][,<source2
>] (see page 476)
:MEASure:DUAL:VPP?
[<source1>][,<source2
>] (see page 476)
<source1>,<source2> ::=
CHANnel<n> with N2820A probe
connected
<n> ::= 1 to (# analog channels)
in NR1 format
<return_value> ::= voltage
peak-to-peak of the selected
waveform in NR3 format
:MEASure:DUAL:VRMS
[<interval>]
[,<type>]
[,<source1>][,<source
2>] (see page 477)
:MEASure:DUAL:VRMS?
[<interval>]
[,<type>]
[,<source1>][,<source
2>] (see page 477)
<interval> ::= {CYCLe | DISPlay}
<type> ::= {AC | DC}
<source1>,<source2> ::=
CHANnel<n> with N2820A probe
connected
<n> ::= 1 to (# analog channels)
in NR1 format
<return_value> ::= calculated
RMS voltage in NR3 format
:MEASure:DUTYcycle
[<source>] (see
page 478)
:MEASure:DUTYcycle?
[<source>] (see
page 478)
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> | FUNCtion<m> |
MATH<m> | WMEMory<r>} for MSO
models
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<return_value> ::= ratio of
positive pulse width to period in
NR3 format
Table 100 :MEASure Commands Summary (continued)
Command Query Options and Query Returns
