Keysight Technologies InfiniiVision 3000T X Series User Manual

:SAVE Commands 28
Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide 669
Introduction to
:SAVE Commands
The :SAVE subsystem provides commands to save oscilloscope setups, screen
images, and data.
:SAV is an acceptable short form for :SAVE.
Reporting the Setup
Use :SAVE? to query setup information for the SAVE subsystem.
Return Format
:SAVE:WAVeform[:STARt
] [<file_name>] (see
page 690)
n/a <file_name> ::= quoted ASCII
string
:SAVE:WAVeform:FORMat
<format> (see
page 691)
:SAVE:WAVeform:FORMat
? (see page 691)
<format> ::= {ASCiixy | CSV |
BINary | NONE}
:SAVE:WAVeform:LENGth
<length> (see
page 692)
:SAVE:WAVeform:LENGth
? (see page 692)
<length> ::= 100 to max. length;
an integer in NR1 format
:SAVE:WAVeform:LENGth
:MAX {{0 | OFF} | {1
| ON}} (see page 693)
:SAVE:WAVeform:LENGth
:MAX? (see page 693)
{0 | 1}
:SAVE:WAVeform:SEGMen
ted <option> (see
page 694)
:SAVE:WAVeform:SEGMen
ted? (see page 694)
<option> ::= {ALL | CURRent}
:SAVE:WMEMory:SOURce
<source> (see
page 695)
:SAVE:WMEMory:SOURce?
(see page 695)
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
NOTE: Only ADD or SUBtract math
operations can be saved as
reference waveforms.
<return_value> ::= <source>
:SAVE:WMEMory[:STARt]
[<file_name>] (see
page 696)
n/a <file_name> ::= quoted ASCII
string
If extension included in file
name, it must be ".h5".
Table 106 :SAVE Commands Summary (continued)
Command Query Options and Query Returns
