Remote control commands
R&S
®
RTE
1493User Manual 1326.1032.02 ─ 20
●
The sources of the serial bus are channel signals: use BUS<m>:...:SOURce
commands.
●
Decoding is enabled: BUS<m>[:STATe] is set to ON.
TRIGger<m>:CAN:TYPE.............................................................................................. 1493
TRIGger<m>:CAN:FDATa:STANdard............................................................................. 1494
TRIGger<m>:CAN:FTYPe.............................................................................................1494
TRIGger<m>:CAN:ITYPe..............................................................................................1495
TRIGger<m>:CAN:ICONdition.......................................................................................1495
TRIGger<m>:CAN:IMIN................................................................................................1495
TRIGger<m>:CAN:IMAX...............................................................................................1496
TRIGger<m>:CAN:FDATa:FDF......................................................................................1496
TRIGger<m>:CAN:FDATa:BRS..................................................................................... 1496
TRIGger<m>:CAN:FDATa:ESI.......................................................................................1496
TRIGger<m>:CAN:DCONdition..................................................................................... 1496
TRIGger<m>:CAN:DMIN.............................................................................................. 1497
TRIGger<m>:CAN:DMAX............................................................................................. 1497
TRIGger<m>:CAN:BORDer.......................................................................................... 1497
TRIGger<m>:CAN:DLCCondition...................................................................................1497
TRIGger<m>:CAN:DLC................................................................................................ 1498
TRIGger<m>:CAN:NDBYtes?........................................................................................1498
TRIGger<m>:CAN:FDATa:DPOPerator...........................................................................1498
TRIGger<m>:CAN:FDATa:DPOSition............................................................................. 1499
TRIGger<m>:CAN:FDATa:DPTO................................................................................... 1499
TRIGger<m>:CAN:ACKerror......................................................................................... 1499
TRIGger<m>:CAN:BITSterror........................................................................................1499
TRIGger<m>:CAN:CRCerror.........................................................................................1500
TRIGger<m>:CAN:FORMerror...................................................................................... 1500
TRIGger<m>:CAN:FDATa:SCERror............................................................................... 1500
TRIGger<m>:CAN:TYPE <Type>
Selects the trigger type for CAN analysis.
See: "Trigger type" on page 567.
Parameters:
<Type> STOF | FTYP | ID | IDDT | ERRC
STOF
STart Of Frame: triggers on the first edge of the dominant SOF
bit (synchronization bit).
FTYP
Frame TYPe: triggers on a specified frame type (data, remote,
error, or overload) and on the identifier format.
To set the frame type, use TRIGger<m>:CAN:FTYPe. ´Set the
identifier format with TRIGger<m>:CAN:ITYPe
Protocols
