2.5.1.23 MSTC Global Status Register (MSTCGSTAT)
The MSTCGSTAT register, shown in Figure 2-30 and described in Table 2-42, shows the status of the
memory hardware initialization and the memory self-test.
Figure 2-30. MSTC Global Status Register (MSTCGSTAT) (offset = 68h)
31 16
Reserved
R-0
15 9 8 7 1 0
Reserved MINIDONE Reserved MSTDONE
R-0 R/WPC-0 R-0 R/WP-0
LEGEND: R/W = Read/Write; R = Read only; C = Clear; WP = Write in privileged mode only; -n = value after reset
Table 2-42. MSTC Global Status Register (MSTCGSTAT) Field Descriptions
Bit Field Value Description
31-9 Reserved 0 Reads return 0. Writes have no effect.
8 MINIDONE Memory hardware initialization complete status.
Note: Disabling the MINITGENA key (By writing from a Ah to any other value) will clear the
MINIDONE status bit to 0.
Note: Individual memory initialization status is shown in the MINISTAT register.
0 Read: Memory hardware initialization is not complete for all memory.
Write: A write of 0 has no effect.
1 Read: Hardware initialization of all memory is completed.
Write: The bit is cleared to 0.
7-1 Reserved 0 Reads return 0. Writes have no effect.
0 MSTDONE Memory self-test run complete status.
Note: Disabling the MSTGENA key (by writing from a Ah to any other value) will clear the
MSTDONE status bit to 0.
0 Read: Memory self-test is not completed.
Write: A write of 0 has no effect.
1 Read: Memory self-test is completed.
Write: The bit is cleared to 0.
