www.ti.com
System and Peripheral Control Registers
185
SPNU563AMarch 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Architecture
2.5.1.32 DFT Control Register (DFTCTRLREG)
This register is shown in Figure 2-39 and described in Table 2-51.
Figure 2-39. DFT Control Register (DFTCTRLREG) (offset = 90h)
31 16
Reserved
R-0
15 14 13 12 11 10 9 8 7 4 3 0
Reserved DFTWRITE Reserved DFTREAD Reserved TEST_MODE_KEY
R-0 R/WP-1h R-0 R/WP-1h R-0 R/WP-5h
LEGEND: R/W = Read/Write; R = Read only; WP = Write in privileged mode only; -n = value after reset
Table 2-51. DFT Control Register (DFTCTRLREG) Field Descriptions
Bit Field Value Description
31-14 Reserved 0 Reads return 0. Writes have no effect.
13-12 DFTWRITE DFT logic access.
For F021:
DFTWRITE[0] = 0 and DFTREAD[0] = 0 configured in stress mode.
DFTWRITE[1] = 0 and DFTREAD[1] = 0 configured in stress mode.
DFTWRITE[0] = 0 and DFTREAD[0] = 0 configured in fast mode.
DFTWRITE[1] = 1 and DFTREAD[1] = 1 configured in fast mode.
DFTWRITE[0] = 1 and DFTREAD[0] = 1 configured in slow mode.
DFTWRITE[1] = 0 and DFTREAD[1] = 0 configured in slow mode.
DFTWRITE[0] = 1 and DFTREAD[0] = 1 configured in screen mode.
DFTWRITE[1] = 1 and DFTREAD[1] = 1 configured in screen mode.
11-10 Reserved 0 Reads return 0. Writes have no effect.
9-8 DFTREAD DFT logic access.
For F021:
DFTWRITE[0] = 0 and DFTREAD[0] = 0 configured in stress mode.
DFTWRITE[1] = 0 and DFTREAD[1] = 0 configured in stress mode.
DFTWRITE[0] = 0 and DFTREAD[0] = 0 configured in fast mode.
DFTWRITE[1] = 1 and DFTREAD[1] = 1 configured in fast mode.
DFTWRITE[0] = 1 and DFTREAD[0] = 1 configured in slow mode.
DFTWRITE[1] = 0 and DFTREAD[1] = 0 configured in slow mode.
DFTWRITE[0] = 1 and DFTREAD[0] = 1 configured in screen mode.
DFTWRITE[1] = 1 and DFTREAD[1] = 1 configured in screen mode.
7-4 Reserved 0 Reads return 0. Writes have no effect.
3-0 TEST_MODE_KEY Test mode key. This register is for internal TI use only.
0 - Fh
(except Ah)
Register key disable. All bits in this register will maintain their default value and cannot be
written.
Ah Register key enable. ALL the bits can be written to only when the key is enabled. On reset,
these bits will be set to 5h.
