EMAC/MDIO Module
32.3.4 EMAC Control Module Receive Threshold Interrupt Enable Registers (C0RXTHRESHEN)
The EMAC control module receive threshold interrupt enable register (C0RXTHRESHEN) is shown in
Figure 32-18 and described in Table 32-14.
Figure 32-18. EMAC Control Module Receive Threshold Interrupt Enable Register
(C0RXTHRESHEN) (offset = 10h)
31 16
Reserved
R-0
15 8
Reserved
R-0
7 6 5 4 3 2 1 0
RXCH7
THRESHEN
RXCH6
THRESHEN
RXCH5
THRESHEN
RXCH4
THRESHEN
RXCH3
THRESHEN
RXCH2
THRESHEN
RXCH1
THRESHEN
RXCH0
THRESHEN
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 32-14. EMAC Control Module Receive Threshold Interrupt Enable Register (C0RXTHRESHEN)
Bit Field Value Description
31-8 Reserved 0 Reserved
7 RXCH7THRESHEN Enable C0RXTHRESHPULSE interrupt generation for RX Channel 7.
0 C0RXTHRESHPULSE generation is disabled for RX Channel 7.
1 C0RXTHRESHPULSE generation is enabled for RX Channel 7.
6 RXCH6THRESHEN Enable C0RXTHRESHPULSE interrupt generation for RX Channel 6.
0 C0RXTHRESHPULSE generation is disabled for RX Channel 6.
1 C0RXTHRESHPULSE generation is enabled for RX Channel 6.
5 RXCH5THRESHEN Enable C0RXTHRESHPULSE interrupt generation for RX Channel 5.
0 C0RXTHRESHPULSE generation is disabled for RX Channel 5.
1 C0RXTHRESHPULSE generation is enabled for RX Channel 5.
4 RXCH4THRESHEN Enable C0RXTHRESHPULSE interrupt generation for RX Channel 4.
0 C0RXTHRESHPULSE generation is disabled for RX Channel 4.
1 C0RXTHRESHPULSE generation is enabled for RX Channel 4.
3 RXCH3THRESHEN Enable C0RXTHRESHPULSE interrupt generation for RX Channel 3.
0 C0RXTHRESHPULSE generation is disabled for RX Channel 3.
1 C0RXTHRESHPULSE generation is enabled for RX Channel 3.
2 RXCH2THRESHEN Enable C0RXTHRESHPULSE interrupt generation for RX Channel 2.
0 C0RXTHRESHPULSE generation is disabled for RX Channel 2.
1 C0RXTHRESHPULSE generation is enabled for RX Channel 2.
1 RXCH1THRESHEN Enable C0RXTHRESHPULSE interrupt generation for RX Channel 1.
0 C0RXTHRESHPULSE generation is disabled for RX Channel 1.
1 C0RXTHRESHPULSE generation is enabled for RX Channel 1.
0 RXCH0THRESHEN Enable C0RXTHRESHPULSE interrupt generation for RX Channel 0.
0 C0RXTHRESHPULSE generation is disabled for RX Channel 0.
1 C0RXTHRESHPULSE generation is enabled for RX Channel 0.
