EMAC/MDIO Module
32.3.6 EMAC Control Module Transmit Interrupt Enable Registers (C0TXEN)
The EMAC control module transmit interrupt enable register (C0TXEN) is shown in Figure 32-20 and
described in Table 32-16
Figure 32-20. EMAC Control Module Transmit Interrupt Enable Register (C0TXEN) (offset = 18h)
31 16
Reserved
R-0
15 8
Reserved
R-0
7 6 5 4 3 2 1 0
TXCH7EN TXCH6EN TXCH5EN TXCH4EN TXCH3EN TXCH2EN TXCH1EN TXCH0EN
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 32-16. EMAC Control Module Transmit Interrupt Enable Register (C0TXEN)
Bit Field Value Description
31-8 Reserved 0 Reserved
7 TXCH7EN Enable C0TXPULSE interrupt generation for TX Channel 7.
0 C0TXPULSE generation is disabled for TX Channel 7.
1 C0TXPULSE generation is enabled for TX Channel 7.
6 TXCH6EN Enable C0TXPULSE interrupt generation for TX Channel 6.
0 C0TXPULSE generation is disabled for TX Channel 6.
1 C0TXPULSE generation is enabled for TX Channel 6.
5 TXCH5EN Enable C0TXPULSE interrupt generation for TX Channel 5.
0 C0TXPULSE generation is disabled for TX Channel 5.
1 C0TXPULSE generation is enabled for TX Channel 5.
4 TXCH4EN Enable C0TXPULSE interrupt generation for TX Channel 4.
0 C0TXPULSE generation is disabled for TX Channel 4.
1 C0TXPULSE generation is enabled for TX Channel 4.
3 TXCH3EN Enable C0TXPULSE interrupt generation for TX Channel 3.
0 C0TXPULSE generation is disabled for TX Channel 3.
1 C0TXPULSE generation is enabled for TX Channel 3.
2 TXCH2EN Enable C0TXPULSE interrupt generation for TX Channel 2.
0 C0TXPULSE generation is disabled for TX Channel 2.
1 C0TXPULSE generation is enabled for TX Channel 2.
1 TXCH1EN Enable C0TXPULSE interrupt generation for TX Channel 1.
0 C0TXPULSE generation is disabled for TX Channel 1.
1 C0TXPULSE generation is enabled for TX Channel 1.
0 TXCH0EN Enable C0TXPULSE interrupt generation for TX Channel 0.
0 C0TXPULSE generation is disabled for TX Channel 0.
1 C0TXPULSE generation is enabled for TX Channel 0.
