EMAC/MDIO Module
32.3.9 EMAC Control Module Receive Interrupt Status Registers (C0RXSTAT)
The EMAC control module receive interrupt status register (C0RXSTAT) is shown in Figure 32-23 and
described in Table 32-19
Figure 32-23. EMAC Control Module Receive Interrupt Status Register (C0RXSTAT) (offset = 44h)
31 16
Reserved
R-0
15 8
Reserved
R-0
7 6 5 4 3 2 1 0
RXCH7STAT RXCH6STAT RXCH5STAT RXCH4STAT RXCH3STAT RXCH2STAT RXCH1STAT RXCH0STAT
R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0
LEGEND: R = Read only; -n = value after reset
Table 32-19. EMAC Control Module Receive Interrupt Status Register (C0RXSTAT)
Bit Field Value Description
31-8 Reserved 0 Reserved
7 RXCH7STAT Interrupt status for RX Channel 7 masked by the C0RXEN register.
0 RX Channel 7 does not satisfy conditions to generate a C0RXPULSE interrupt.
1 RX Channel 7 satisfies conditions to generate a C0RXPULSE interrupt.
6 RXCH6STAT Interrupt status for RX Channel 6 masked by the C0RXEN register.
0 RX Channel 6 does not satisfy conditions to generate a C0RXPULSE interrupt.
1 RX Channel 6 satisfies conditions to generate a C0RXPULSE interrupt.
5 RXCH5STAT Interrupt status for RX Channel 5 masked by the C0RXEN register.
0 RX Channel 5 does not satisfy conditions to generate a C0RXPULSE interrupt.
1 RX Channel 5 satisfies conditions to generate a C0RXPULSE interrupt.
4 RXCH4STAT Interrupt status for RX Channel 4 masked by the C0RXEN register.
0 RX Channel 4 does not satisfy conditions to generate a C0RXPULSE interrupt.
1 RX Channel 4 satisfies conditions to generate a C0RXPULSE interrupt.
3 RXCH3STAT Interrupt status for RX Channel 3 masked by the C0RXEN register.
0 RX Channel 3 does not satisfy conditions to generate a C0RXPULSE interrupt.
1 RX Channel 3 satisfies conditions to generate a C0RXPULSE interrupt.
2 RXCH2STAT Interrupt status for RX Channel 2 masked by the C0RXEN register.
0 RX Channel 2 does not satisfy conditions to generate a C0RXPULSE interrupt.
1 RX Channel 2 satisfies conditions to generate a C0RXPULSE interrupt.
1 RXCH1STAT Interrupt status for RX Channel 1 masked by the C0RXEN register.
0 RX Channel 1 does not satisfy conditions to generate a C0RXPULSE interrupt.
1 RX Channel 1 satisfies conditions to generate a C0RXPULSE interrupt.
0 RXCH0STAT Interrupt status for RX Channel 0 masked by the C0RXEN register.
0 RX Channel 0 does not satisfy conditions to generate a C0RXPULSE interrupt.
1 RX Channel 0 satisfies conditions to generate a C0RXPULSE interrupt.
