EMAC/MDIO Module
32.4.8 MDIO User Command Complete Interrupt (Masked) Register (USERINTMASKED)
The MDIO user command complete interrupt (masked) register (USERINTMASKED) is shown in
Figure 32-35 and described in Table 32-32.
Figure 32-35. MDIO User Command Complete Interrupt (Masked) Register (USERINTMASKED)
(offset = 24h)
31 16
Reserved
R-0
15 2 1 0
Reserved USERACCESS1 USERACCESS0
R-0 R/W1C-0 R/W1C-0
LEGEND: R/W = Read/Write; R = Read only; W1C = Write 1 to clear (writing a 0 has no effect); -n = value after reset
Table 32-32. MDIO User Command Complete Interrupt (Masked) Register (USERINTMASKED)
Field Descriptions
Bit Field Value Description
31-2 Reserved 0 Reserved
1 USERACCESS1 Masked value of MDIO User command complete interrupt. When asserted, The bit indicates
that the previously scheduled PHY read or write command using that particular
USERACCESS1 register has completed. Writing a 1 will clear the interrupt, writing a 0 has no
effect.
0 No MDIO user command complete event.
1 The previously scheduled PHY read or write command using MDIO user access register
USERACCESS1 has completed and the corresponding bit in USERINTMASKSET is set to 1.
0 USERACCESS0 Masked value of MDIO User command complete interrupt. When asserted, The bit indicates
that the previously scheduled PHY read or write command using that particular
USERACCESS0 register has completed. Writing a 1 will clear the interrupt, writing a 0 has no
effect.
0 No MDIO user command complete event.
1 The previously scheduled PHY read or write command using MDIO user access register
USERACCESS0 has completed and the corresponding bit in USERINTMASKSET is set to 1.
