Data Modification Module (DMM)
36.3.3 DMM Interrupt Clear Register (DMMINTCLR)
This register contains the interrupt clear bits for error interrupts and functional interrupts. Only the bits
which are relevant for the particular mode (trace mode or direct data mode) will be taken into account for
the interrupt generation
Figure 36-9. DMM Interrupt Clear Register (DMMINTCLR) [offset = 08h]
31 24
Reserved
R-0
23 18 17 16
Reserved PROG_BUFF EO_BUFF
R-0 R/WP-0 R/WP-0
15 14 13 12 11 10 9 8
DEST3REG2 DEST3REG1 DEST2REG2 DEST2REG1 DEST1REG2 DEST1REG1 DEST0REG2 DEST0REG1
R/WP-0 R/WP-0 R/WP-0 R/WP-0 R/WP-0 R/WP-0 R/WP-0 R/WP-0
7 6 5 4 3 2 1 0
BUSERROR BUFF_OVF SRC_OVF DEST3_ERR DEST2_ERR DEST1_ERR DEST0_ERR PACKET_
ERR_INT
R/WP-0 R/WP-0 R/WP-0 R/WP-0 R/WP-0 R/WP-0 R/WP-0 R/WP-0
LEGEND: R/W = Read/Write; R = Read only; WP = Write in privileged mode only; -n = value after reset
Table 36-9. DMM Interrupt Clear Register (DMMINTCLR) Field Descriptions
Bit Field Value Description
31-18 Reserved 0 Reads returns 0. Writes have no effect.
17 PROG_BUFF Programmable Buffer Interrupt Set.This disables the interrupt generation in case the buffer
pointer equals the programmed value in the DMMINTPT register (Section 36.3.11). This bit is
only relevant in Direct Data Mode.
User and privilege mode (read):
0 No interrupt will be generated.
1 An interrupt will be generated on pointer match.
Privilege mode (write):
0 No influence on bit.
1 Disable interrupt (clears corresponding bit in DMMINTCLR; DMM Interrupt Level Register
(DMMINTLVL)).
16 EO_BUFF End of Buffer Interrupt Set.This disables the interrupt generation in case data was written to
the last entry in the buffer and the pointer wrapped around to the beginning of the buffer. This
bit is only relevant in Direct Data Mode.
User and privilege mode (read):
0 No interrupt will be generated.
1 An interrupt will be generated on writing to the last entry.
Privilege mode (write):
0 No influence on bit.
1 Disable interrupt (clears corresponding bit in DMMINTCLR; DMM Interrupt Level Register
(DMMINTLVL)).
