Example Configuration
www.ti.com
844
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
External Memory Interface (EMIF)
Figure 21-30. SDRAM Refresh Control Register (SDRCR)
31 19 18 16
0 0000 0000 0000 000
Reserved Reserved
15 13 12 0
000 0 0110 0001 1010 (61Ah)
Reserved RR
21.4.2.1.5 SDRAM Configuration Register (SDCR) Settings for the EMIF to K4S641632H-TC(L)70
Interface
Finally, the fields of the SDRAM configuration register (SDCR) should be programmed as described in
Table 21-37 to properly interface with the K4S641632H-TC(L)70 device. Based on these settings, a value
of 4720h should be written to SDCR. Figure 21-31 shows how SDCR should be programmed. The EMIF is
now ready to perform read and write accesses to the SDRAM.
Table 21-41. SDCR Field Values For the EMIF to K4S641632H-TC(L)70 Interface
Field Value Purpose
SR 0 To avoid placing the EMIF into the self refresh state
NM 1 To configure the EMIF for a 16-bit data bus
CL 011b To select a CAS latency of 3
BIT11_9LOCK 1 To allow the CL field to be written
IBANK 010b To select 4 internal SDRAM banks
PAGESIZE 0 To select a page size of 256 words
Figure 21-31. SDRAM Configuration Register (SDCR)
31 30 29 28 24
0 0 0 0 0000
SR Reserved Reserved Reserved
23 18 17 16
00 0000 0 0
Reserved Reserved Reserved
15 14 13 12 11 9 8
0 1 0 0 011 1
Reserved NM Reserved Reserved CL BIT11_9LOCK
7 6 4 3 2 0
0 010 0 000
Reserved IBANK Reserved PAGESIZE
