122 Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:SBUS<n>:FLEXray:SOUR
ce <source> (see
page 757)
:SBUS<n>:FLEXray:SOUR
ce? (see page 757)
<source> ::= {CHANnel<n>}
<n> ::= 1-2 or 1-4 in NR1 format
:SBUS<n>:FLEXray:TRIG
ger <condition> (see
page 758)
:SBUS<n>:FLEXray:TRIG
ger? (see page 758)
<condition> ::= {FRAMe | ERRor |
EVENt}
:SBUS<n>:FLEXray:TRIG
ger:ERRor:TYPE
<error_type> (see
page 759)
:SBUS<n>:FLEXray:TRIG
ger:ERRor:TYPE? (see
page 759)
<error_type> ::= {ALL | HCRC |
FCRC}
:SBUS<n>:FLEXray:TRIG
ger:EVENt:AUToset
(see page 760)
n/a n/a
:SBUS<n>:FLEXray:TRIG
ger:EVENt:BSS:ID
<frame_id> (see
page 761)
:SBUS<n>:FLEXray:TRIG
ger:EVENt:BSS:ID?
(see page 761)
<frame_id> ::= {ALL | <frame #>}
<frame #> ::= integer from 1-2047
:SBUS<n>:FLEXray:TRIG
ger:EVENt:TYPE
<event> (see page 762)
:SBUS<n>:FLEXray:TRIG
ger:EVENt:TYPE? (see
page 762)
<event> ::= {WAKeup | TSS | {FES
| DTS} | BSS}
:SBUS<n>:FLEXray:TRIG
ger:FRAMe:CCBase
<cycle_count_base>
(see page 763)
:SBUS<n>:FLEXray:TRIG
ger:FRAMe:CCBase?
(see page 763)
<cycle_count_base> ::= integer
from 0-63
:SBUS<n>:FLEXray:TRIG
ger:FRAMe:CCRepetitio
n
<cycle_count_repetiti
on> (see page 764)
:SBUS<n>:FLEXray:TRIG
ger:FRAMe:CCRepetitio
n? (see page 764)
<cycle_count_repetition> ::=
{ALL | <rep #>}
<rep #> ::= integer values 2, 4,
8, 16, 32, or 64
:SBUS<n>:FLEXray:TRIG
ger:FRAMe:ID
<frame_id> (see
page 765)
:SBUS<n>:FLEXray:TRIG
ger:FRAMe:ID? (see
page 765)
<frame_id> ::= {ALL | <frame #>}
<frame #> ::= integer from 1-2047
:SBUS<n>:FLEXray:TRIG
ger:FRAMe:TYPE
<frame_type> (see
page 766)
:SBUS<n>:FLEXray:TRIG
ger:FRAMe:TYPE? (see
page 766)
<frame_type> ::= {NORMal |
STARtup | NULL | SYNC | NSTArtup
| NNULl | NSYNc | ALL}
Table 28 :SBUS<n>:FLEXray Commands Summary (continued)
Command Query Options and Query Returns
