Keysight Technologies InfiniiVision 3000T X Series User Manual

Commands Quick Reference 4
Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide 121
:SBUS<n>:CAN:TRIGger:
PATTern:DATA:STARt
<start> (see page 742)
:SBUS<n>:CAN:TRIGger:
PATTern:DATA:STARt?
(see page 742)
<start> ::= integer between 0 and
63, in NR1 format.
:SBUS<n>:CAN:TRIGger:
PATTern:ID <string>
(see page 743)
:SBUS<n>:CAN:TRIGger:
PATTern:ID? (see
page 743)
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $}
<string ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
:SBUS<n>:CAN:TRIGger:
PATTern:ID:MODE
<value> (see page 744)
:SBUS<n>:CAN:TRIGger:
PATTern:ID:MODE? (see
page 744)
<value> ::= {STANdard | EXTended}
:SBUS<n>:CAN:TRIGger:
SYMBolic:MESSage
<name> (see page 745)
:SBUS<n>:CAN:TRIGger:
SYMBolic:MESSage?
(see page 745)
<name> ::= quoted ASCII string
:SBUS<n>:CAN:TRIGger:
SYMBolic:SIGNal
<name> (see page 746)
:SBUS<n>:CAN:TRIGger:
SYMBolic:SIGNal? (see
page 746)
<name> ::= quoted ASCII string
:SBUS<n>:CAN:TRIGger:
SYMBolic:VALue <data>
(see page 747)
:SBUS<n>:CAN:TRIGger:
SYMBolic:VALue? (see
page 747)
<data> ::= value in NR3 format
Table 27 :SBUS<n>:CAN Commands Summary (continued)
Command Query Options and Query Returns
Table 28 :SBUS<n>:FLEXray Commands Summary
Command Query Options and Query Returns
:SBUS<n>:FLEXray:AUTo
setup (see page 750)
n/a n/a
:SBUS<n>:FLEXray:BAUD
rate <baudrate> (see
page 751)
:SBUS<n>:FLEXray:BAUD
rate? (see page 751)
<baudrate> ::= {2500000 | 5000000
| 10000000}
:SBUS<n>:FLEXray:CHAN
nel <channel> (see
page 752)
:SBUS<n>:FLEXray:CHAN
nel? (see page 752)
<channel> ::= {A | B}
n/a :SBUS<n>:FLEXray:COUN
t:NULL? (see page 753)
<frame_count> ::= integer in NR1
format
:SBUS<n>:FLEXray:COUN
t:RESet (see page 754)
n/a n/a
n/a :SBUS<n>:FLEXray:COUN
t:SYNC? (see page 755)
<frame_count> ::= integer in NR1
format
n/a :SBUS<n>:FLEXray:COUN
t:TOTal? (see
page 756)
<frame_count> ::= integer in NR1
format
