Keysight Technologies InfiniiVision 3000T X Series User Manual

120 Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:SBUS<n>:CAN:SIGNal:B
AUDrate <baudrate>
(see page 731)
:SBUS<n>:CAN:SIGNal:B
AUDrate? (see
page 731)
<baudrate> ::= integer from 10000
to 4000000 in 100 b/s increments,
or 5000000
:SBUS<n>:CAN:SIGNal:D
EFinition <value>
(see page 732)
:SBUS<n>:CAN:SIGNal:D
EFinition? (see
page 732)
<value> ::= {CANH | CANL | RX |
TX | DIFFerential | DIFL | DIFH}
:SBUS<n>:CAN:SIGNal:F
DBaudrate <baudrate>
(see page 733)
:SBUS<n>:CAN:SIGNal:F
DBaudrate? (see
page 733)
<baudrate> ::= integer from 10000
to 10000000 in 100 b/s
increments.
:SBUS<n>:CAN:SOURce
<source> (see
page 734)
:SBUS<n>:CAN:SOURce?
(see page 734)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> |} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:CAN:TRIGger
<condition> (see
page 735)
:SBUS<n>:CAN:TRIGger?
(see page 736)
<condition> ::= {SOF | EOF |
IDData | DATA | FDData | IDRemote
| IDEither | ERRor | ACKerror |
FORMerror | STUFferror | CRCerror
| SPECerror | ALLerrors | BRSBit
| CRCDbit | EBActive | EBPassive
| OVERload | MESSage | MSIGnal |
FDMSignal}
:SBUS<n>:CAN:TRIGger:
IDFilter {{0 | OFF} |
{1 | ON}} (see
page 738)
:SBUS<n>:CAN:TRIGger:
IDFilter? (see
page 738)
{0 | 1}
:SBUS<n>:CAN:TRIGger:
PATTern:DATA <string>
(see page 739)
:SBUS<n>:CAN:TRIGger:
PATTern:DATA? (see
page 739)
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $}
<string ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
:SBUS<n>:CAN:TRIGger:
PATTern:DATA:DLC
<dlc> (see page 740)
:SBUS<n>:CAN:TRIGger:
PATTern:DATA:DLC?
(see page 740)
<dlc> ::= integer between -1
(don't care) and 64, in NR1
format.
:SBUS<n>:CAN:TRIGger:
PATTern:DATA:LENGth
<length> (see
page 741)
:SBUS<n>:CAN:TRIGger:
PATTern:DATA:LENGth?
(see page 741)
<length> ::= integer from 1 to 8
in NR1 format
Table 27 :SBUS<n>:CAN Commands Summary (continued)
Command Query Options and Query Returns
