Commands Quick Reference 4
Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide 131
:SBUS<n>:SPI:TRIGger:
PATTern:MISO:DATA
<string> (see
page 860)
:SBUS<n>:SPI:TRIGger:
PATTern:MISO:DATA?
(see page 860)
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $}
<string ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
:SBUS<n>:SPI:TRIGger:
PATTern:MISO:WIDTh
<width> (see page 861)
:SBUS<n>:SPI:TRIGger:
PATTern:MISO:WIDTh?
(see page 861)
<width> ::= integer from 4 to 64
in NR1 format
:SBUS<n>:SPI:TRIGger:
PATTern:MOSI:DATA
<string> (see
page 862)
:SBUS<n>:SPI:TRIGger:
PATTern:MOSI:DATA?
(see page 862)
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $}
<string ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
:SBUS<n>:SPI:TRIGger:
PATTern:MOSI:WIDTh
<width> (see page 863)
:SBUS<n>:SPI:TRIGger:
PATTern:MOSI:WIDTh?
(see page 863)
<width> ::= integer from 4 to 64
in NR1 format
:SBUS<n>:SPI:TRIGger:
TYPE <value> (see
page 864)
:SBUS<n>:SPI:TRIGger:
TYPE? (see page 864)
<value> ::= {MOSI | MISO}
:SBUS<n>:SPI:WIDTh
<word_width> (see
page 865)
:SBUS<n>:SPI:WIDTh?
(see page 865)
<word_width> ::= integer 4-16 in
NR1 format
Table 34 :SBUS<n>:SPI Commands Summary (continued)
Command Query Options and Query Returns
Table 35 :SBUS<n>:UART Commands Summary
Command Query Options and Query Returns
:SBUS<n>:UART:BASE
<base> (see page 869)
:SBUS<n>:UART:BASE?
(see page 869)
<base> ::= {ASCii | BINary | HEX}
:SBUS<n>:UART:BAUDrat
e <baudrate> (see
page 870)
:SBUS<n>:UART:BAUDrat
e? (see page 870)
<baudrate> ::= integer from 100
to 8000000
:SBUS<n>:UART:BITorde
r <bitorder> (see
page 871)
:SBUS<n>:UART:BITorde
r? (see page 871)
<bitorder> ::= {LSBFirst |
MSBFirst}
n/a :SBUS<n>:UART:COUNt:E
RRor? (see page 872)
<frame_count> ::= integer in NR1
format
:SBUS<n>:UART:COUNt:R
ESet (see page 873)
n/a n/a
n/a :SBUS<n>:UART:COUNt:R
XFRames? (see
page 874)
<frame_count> ::= integer in NR1
format
