132 Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
n/a :SBUS<n>:UART:COUNt:T
XFRames? (see
page 875)
<frame_count> ::= integer in NR1
format
:SBUS<n>:UART:FRAMing
<value> (see page 876)
:SBUS<n>:UART:FRAMing
? (see page 876)
<value> ::= {OFF | <decimal> |
<nondecimal>}
<decimal> ::= 8-bit integer from
0-255 (0x00-0xff)
<nondecimal> ::= #Hnn where n ::=
{0,..,9 | A,..,F} for hexadecimal
<nondecimal> ::= #Bnn...n where n
::= {0 | 1} for binary
:SBUS<n>:UART:PARity
<parity> (see
page 877)
:SBUS<n>:UART:PARity?
(see page 877)
<parity> ::= {EVEN | ODD | NONE}
:SBUS<n>:UART:POLarit
y <polarity> (see
page 878)
:SBUS<n>:UART:POLarit
y? (see page 878)
<polarity> ::= {HIGH | LOW}
:SBUS<n>:UART:SOURce:
RX <source> (see
page 879)
:SBUS<n>:UART:SOURce:
RX? (see page 879)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d>} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:UART:SOURce:
TX <source> (see
page 880)
:SBUS<n>:UART:SOURce:
TX? (see page 880)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d>} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:UART:TRIGger
:BASE <base> (see
page 881)
:SBUS<n>:UART:TRIGger
:BASE? (see page 881)
<base> ::= {ASCii | HEX}
:SBUS<n>:UART:TRIGger
:BURSt <value> (see
page 882)
:SBUS<n>:UART:TRIGger
:BURSt? (see page 882)
<value> ::= {OFF | 1 to 4096 in
NR1 format}
Table 35 :SBUS<n>:UART Commands Summary (continued)
Command Query Options and Query Returns
