80 Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
Table 9 :DEMO Commands Summary
Command Query Options and Query Returns
:DEMO:FUNCtion
<signal> (see
page 300)
:DEMO:FUNCtion? (see
page 303)
<signal> ::= {SINusoid | NOISy |
PHASe | RINGing | SINGle | AM |
CLK | GLITch | BURSt | MSO | RUNT
| TRANsition | RFBurst | SHOLd |
LFSine | FMBurst | ETE | CAN |
LIN | UART | I2C | SPI | I2S |
CANLin | ARINc | FLEXray | MIL |
MIL2 | USB | NMONotonic}
:DEMO:FUNCtion:PHASe:
PHASe <angle> (see
page 304)
:DEMO:FUNCtion:PHASe:
PHASe? (see page 304)
<angle> ::= angle in degrees from
0 to 360 in NR3 format
:DEMO:OUTPut {{0 |
OFF} | {1 | ON}} (see
page 305)
:DEMO:OUTPut? (see
page 305)
{0 | 1}
Table 10 :DIGital<d> Commands Summary
Command Query Options and Query Returns
:DIGital<d>:DISPlay
{{0 | OFF} | {1 |
ON}} (see page 309)
:DIGital<d>:DISPlay?
(see page 309)
<d> ::= 0 to (# digital channels
- 1) in NR1 format
{0 | 1}
:DIGital<d>:LABel
<string> (see
page 310)
:DIGital<d>:LABel?
(see page 310)
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<string> ::= any series of 10 or
less ASCII characters enclosed in
quotation marks
:DIGital<d>:POSition
<position> (see
page 311)
:DIGital<d>:POSition?
(see page 311)
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<position> ::= 0-7 if display
size = large, 0-15 if size =
medium, 0-31 if size = small
Returns -1 when there is no space
to display the digital waveform.
