Keysight Technologies InfiniiVision 3000T X Series User Manual

Commands Quick Reference 4
Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide 81
:DIGital<d>:SIZE
<value> (see page 312)
:DIGital<d>:SIZE?
(see page 312)
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<value> ::= {SMALl | MEDium |
LARGe}
:DIGital<d>:THReshold
<value>[suffix] (see
page 313)
:DIGital<d>:THReshold
? (see page 313)
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<value> ::= {CMOS | ECL | TTL |
<user defined value>}
<user defined value> ::= value in
NR3 format from -8.00 to +8.00
[suffix] ::= {V | mV | uV}
Table 10 :DIGital<d> Commands Summary (continued)
Command Query Options and Query Returns
Table 11 :DISPlay Commands Summary
Command Query Options and Query Returns
:DISPlay:ANNotation<n
> {{0 | OFF} | {1 |
ON}} (see page 318)
:DISPlay:ANNotation<n
>? (see page 318)
{0 | 1}
<n> ::= an integer from 1 to 4 in
NR1 format.
:DISPlay:ANNotation<n
>:BACKground <mode>
(see page 319)
:DISPlay:ANNotation<n
>:BACKground? (see
page 319)
<mode> ::= {OPAQue | INVerted |
TRANsparent}
<n> ::= an integer from 1 to 4 in
NR1 format.
:DISPlay:ANNotation<n
>:COLor <color> (see
page 320)
:DISPlay:ANNotation<n
>:COLor? (see
page 320)
<color> ::= {CH1 | CH2 | CH3 |
CH4 | DIG | MATH | REF | MARKer |
WHITe | RED}
<n> ::= an integer from 1 to 4 in
NR1 format.
:DISPlay:ANNotation<n
>:TEXT <string> (see
page 321)
:DISPlay:ANNotation<n
>:TEXT? (see page 321)
<string> ::= quoted ASCII string
(up to 254 characters)
<n> ::= an integer from 1 to 4 in
NR1 format.
:DISPlay:ANNotation<n
>:X1Position <value>
(see page 322)
:DISPlay:ANNotation<n
>:X1Position? (see
page 322)
<value> ::= an integer from 0 to
(800 - width of annotation) in
NR1 format.
<n> ::= an integer from 1 to 4 in
NR1 format.
:DISPlay:ANNotation<n
>:Y1Position <value>
(see page 323)
:DISPlay:ANNotation<n
>:Y1Position? (see
page 323)
<value> ::= an integer from 0 to
(480 - height of annotation) in
NR1 format.
<n> ::= an integer from 1 to 4 in
NR1 format.
