Architecture
2.5.1.12 Clock Source Disable Clear Register (CSDISCLR)
The CSDISCLR register, shown in Figure 2-19 and described in Table 2-31, clears clock sources to the
enabled state.
Figure 2-19. Clock Source Disable Clear Register (CSDISCLR) (offset = 38h)
31 8
Reserved
R-0
7 6 5 4 3 2 1 0
CLRCLKSR7
OFF
CLRCLKSR6
OFF
CLRCLKSR5
OFF
CLRCLKSR4
OFF
CLRCLKSR3
OFF
Reserved CLRCLKSR1
OFF
CLRCLKSR0
OFF
R/WP-1 R/WP-1 R/WP-0 R/WP-0 R/WP-1 R-1 R/WP-1 R/WP-0
LEGEND: R/W = Read/Write; R = Read only; WP = Write in privileged mode only; -n = value after reset
Table 2-31. Clock Source Disable Clear Register (CSDISCLR) Field Descriptions
Bit Field Value Description
31-8 Reserved 0 Reads return 0. Writes have no effect.
7-3 CLRCLKSR[7-3]OFF Enables clock source[7-3].
0 Read: Clock source[7-3] is enabled.
Write: Clock source[7-3] is unchanged.
1 Read: Clock source[7-3] is enabled.
Write: Clock source[7-3] is set to the enabled state.
Note: After a new clock source disable bit is set via the CSDISSET register, the new
status of the bit will be reflected in the CSDIS register (offset 30h), the CSDISSET
register (offset 34h), and the CSDISCLR register (offset 38h).
2 Reserved 1 Reads return 1. Writes have no effect.
1-0 CLRCLKSR[1-0]OFF Enables clock source[1-0].
0 Read: Clock source[1-0] is enabled.
Write: Clock source[1-0] is unchanged.
1 Read: Clock source[1-0] is enabled.
Write: Clock source[1-0] is set to the enabled state.
Note: After a new clock source disable bit is set via the CSDISSET register, the new
status of the bit will be reflected in the CSDIS register (offset 30h), the CSDISSET
register (offset 34h) and the CSDISCLR register (offset 38h).
NOTE: A list of the available clock sources is shown in the Table 2-29.
