:FUNCtion<m> Commands 18
Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide 367
:FUNCtion<m>:INTegrat
e:IOFFset
<input_offset> (see
page 386)
:FUNCtion<m>:INTegrat
e:IOFFset? (see
page 386)
<input_offset> ::= DC offset
correction in NR3 format.
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:LINear:G
AIN <value> (see
page 387)
:FUNCtion<m>:LINear:G
AIN? (see page 387)
<value> ::= 'A' in Ax + B, value
in NR3 format
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:LINear:O
FFSet <value> (see
page 388)
:FUNCtion<m>:LINear:O
FFSet? (see page 388)
<value> ::= 'B' in Ax + B, value
in NR3 format
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:OFFSet
<offset> (see
page 389)
:FUNCtion<m>:OFFSet?
(see page 389)
<offset> ::= the value at center
screen in NR3 format.
The range of legal values is
+/-10 times the current
sensitivity of the selected
function.
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:OPERatio
n <operation> (see
page 390)
:FUNCtion<m>:OPERatio
n? (see page 392)
<operation> ::= {ADD | SUBTract |
MULTiply | DIVide | INTegrate |
DIFF | FFT | SQRT | MAGNify |
ABSolute | SQUare | LN | LOG |
EXP | TEN | LOWPass | HIGHpass |
AVERage | LINear | TRENd |
BTIMing | BSTate}
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:RANGe
<range> (see page 394)
:FUNCtion<m>:RANGe?
(see page 394)
<range> ::= the full-scale
vertical axis value in NR3
format.
The range for ADD, SUBT, MULT is
8E-6 to 800E+3. The range for the
INTegrate function is 8E-9 to
400E+3.
The range for the DIFF function
is 80E-3 to 8.0E12 (depends on
current sweep speed).
The range for the FFT function is
8 to 800 dBV.
<m> ::= 1 to (# math functions)
in NR1 format
Table 96 :FUNCtion<m> Commands Summary (continued)
