86 Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:FUNCtion<m>[:FFT]:VT
YPe <units> (see
page 382)
:FUNCtion<m>[:FFT]:VT
YPe? (see page 382)
<units> ::= {DECibel | VRMS}
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>[:FFT]:WI
NDow <window> (see
page 383)
:FUNCtion<m>[:FFT]:WI
NDow? (see page 383)
<window> ::= {RECTangular |
HANNing | FLATtop | BHARris}
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:FREQuenc
y:HIGHpass <3dB_freq>
(see page 384)
:FUNCtion<m>:FREQuenc
y:HIGHpass? (see
page 384)
<3dB_freq> ::= 3dB cutoff
frequency value in NR3 format
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:FREQuenc
y:LOWPass <3dB_freq>
(see page 385)
:FUNCtion<m>:FREQuenc
y:LOWPass? (see
page 385)
<3dB_freq> ::= 3dB cutoff
frequency value in NR3 format
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:INTegrat
e:IOFFset
<input_offset> (see
page 386)
:FUNCtion<m>:INTegrat
e:IOFFset? (see
page 386)
<input_offset> ::= DC offset
correction in NR3 format.
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:LINear:G
AIN <value> (see
page 387)
:FUNCtion<m>:LINear:G
AIN? (see page 387)
<value> ::= 'A' in Ax + B, value
in NR3 format
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:LINear:O
FFSet <value> (see
page 388)
:FUNCtion<m>:LINear:O
FFSet? (see page 388)
<value> ::= 'B' in Ax + B, value
in NR3 format
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:OFFSet
<offset> (see
page 389)
:FUNCtion<m>:OFFSet?
(see page 389)
<offset> ::= the value at center
screen in NR3 format.
The range of legal values is
+/-10 times the current
sensitivity of the selected
function.
<m> ::= 1 to (# math functions)
in NR1 format
Table 15 :FUNCtion<m> Commands Summary (continued)
Command Query Options and Query Returns
