Keysight Technologies InfiniiVision 3000T X Series User Manual

Commands Quick Reference 4
Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide 87
:FUNCtion<m>:OPERatio
n <operation> (see
page 390)
:FUNCtion<m>:OPERatio
n? (see page 392)
<operation> ::= {ADD | SUBTract |
MULTiply | DIVide | INTegrate |
DIFF | FFT | SQRT | MAGNify |
ABSolute | SQUare | LN | LOG |
EXP | TEN | LOWPass | HIGHpass |
AVERage | LINear | TRENd |
BTIMing | BSTate}
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:RANGe
<range> (see page 394)
:FUNCtion<m>:RANGe?
(see page 394)
<range> ::= the full-scale
vertical axis value in NR3
format.
The range for ADD, SUBT, MULT is
8E-6 to 800E+3. The range for the
INTegrate function is 8E-9 to
400E+3.
The range for the DIFF function
is 80E-3 to 8.0E12 (depends on
current sweep speed).
The range for the FFT function is
8 to 800 dBV.
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:REFerenc
e <level> (see
page 395)
:FUNCtion<m>:REFerenc
e? (see page 395)
<level> ::= the value at center
screen in NR3 format.
The range of legal values is
+/-10 times the current
sensitivity of the selected
function.
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:SCALe
<scale
value>[<suffix>] (see
page 396)
:FUNCtion<m>:SCALe?
(see page 396)
<scale value> ::= integer in NR1
format
<suffix> ::= {V | dB}
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:SMOoth:P
OINts <points> (see
page 397)
:FUNCtion<m>:SMOoth:P
OINts? (see page 397)
<points> ::= odd integer in NR1
format
Table 15 :FUNCtion<m> Commands Summary (continued)
Command Query Options and Query Returns
