Network structures
6.1 VLAN
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
194 Configuration Manual, 06/2016, C79000-G8976-C252-11
The parameters have the following meaning:
Parameter
Description
Range of values / note
ip
Internet Protocol v4
HEX 08:00
novell
Novell Netware protocol
HEX 81:38
netbios
Netbios via TCP/IP
HEX f0:f0
appletalk
Appletalk
HEX 80:9b
other
Other protocol. enter the hexadecimal protocol
value.
• other: aa:aa
• IPV6:
86:DD
• LLDP:
88:CC
• PTP IEEE1588:
88:F7
• EAP (802.1X):
88:8E
enet-v2
Frame structure is Ethernet II
-
Result
The protocol is removed from all protocol groups.
Further notes
You create the protocol group with the map protocol command.
You can display the status of this function and other information with the
show vlan
protocols-group
command.
6.1.2.5
protocol-vlan
Description
With this command, you enable the protocol-based classification on all interfaces.
Requirement
You are in the Global Configuration mode.
The command prompt is as follows:
cli(config)#
Syntax
Call the command without parameters:
protocol-vlan
