Page #199 background imageLoading...
Page #199 background image
Network structures
6.1 VLAN
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 06/2016, C79000-G8976-C252-11
199
Syntax
Call up the command with the following parameters:
vlan range <vlan-id(1-4094)> - <vlan-id(2-4094)>
The parameters have the following meaning:
Parameter
Description
Range of values / note
vlan-id
Number of the addressed VLAN
1 ... 4094
vlan-id
Number of the addressed VLAN 2 ... 4094
Enter a space before and after the hyphen, e.g. vlan range 5 - 10.
For information on names of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 42)".
Result
The command prompt is as follows:
CLI(config-vlan-range)#
Configuration commands you enter with this command prompt apply to all selected VLANs.
Further notes
With the command exit, you return to the Global configuration mode.
6.1.3
Commands in the interface configuration mode
This section describes commands that you can call up in the interface configuration mode.
Depending on the Interface selected, various command sets are available.
In the Global configuration mode, enter the
interface command to change to this mode.
Commands relating to other topics that can be called in the interface configuration mode can
be found in the relevant sections.
If you exit the Interface configuration mode with the
exit command, you return to the
Global configuration mode.
If you exit the Interface configuration mode with the
end command, you return to the
Privileged EXEC mode.
6.1.3.1
map subnet
Description
With this command, you configure IPv4 subnet-based VLAN.
