Siemens SCALANCE XM-400 Configuration Manual

Network structures
6.1 VLAN
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
222 Configuration Manual, 06/2016, C79000-G8976-C252-11
The parameters have the following meaning:
Parameter
Description
Range of values / note
interface-type
Type of interface
Enter a valid interface.
/a-b,0/c,...
Port no. of the interface
port-channel
Keyword for a port channel
-
a,b,c-d
Port no. of the interface
Enter a valid interface.
untagged
Keyword for interfaces or ports that transfer
data packets without VLAN marking
-
all
Specifies that all interfaces or ports are set
to "untagged"
-
forbidden
Keyword for forbidden interfaces or ports
-
name
Keyword for the name assignment
-
vlan-name
Name of the VLAN
max. 32 characters
For information on names of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 42)".
Result
The ports are removed from the VLAN configuration.
Further notes
It is possible to remove individual ports from a VLAN configuration without needing to rewrite
the entire configuration (in contrast to creating ports because it is not possible to add
individual ports later).
You display details of the function with the
show vlan command.
You configure the setting with the
ports command.
6.1.4.5
private-vlan
Description
With this command you define a VLAN as a private VLAN and specify the PVLAN type.
Requirement
You are in the VLAN Configuration mode.
The command prompt is as follows:
cli(config-vlan-$$$)#
