Layer 3 functions
9.2 OSPFv2 (IPv4)
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
526 Configuration Manual, 06/2016, C79000-G8976-C252-11
9.2.3.4
area range summary
Description
With this command, you assign an area ID an address range. The address range is used to
group the routes within OSPF.
Note
This command is available only with layer 3.
Requirement
You are in the OSPF Router configuration mode.
The command prompt is as follows:
cli(config-ospf)#
Syntax
Call up the command with the following parameters:
area <AreaId> range
<Network>
<Mask>
{
summary | Type7
}
[{
advertise | notadvertise
}]
The parameters have the following meaning:
Parameter
Description
Range of values / note
AreaId
Area-ID specify an ID.
x.x.x.x
x = 0 ... 255
0.0.0.0 = backbone area
Network
IP address of the address range
specify the IP address
Mask
Subnet mask of the address range
specify the subnet mask.
summary
Summary LSA
-
Type7
LSA type 7
-
advertise
The address range is advertised out-
side the ranges.
If the Area ID is 0.0.0.0, the router
generates an LSA message of Type 5.
If the Area ID is not 0.0.0.0, the router
generates an LSA message of Type 7
in an NSSA.
-
