Siemens SCALANCE XM-400 Configuration Manual

Network structures
6.3 Spanning Tree
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 06/2016, C79000-G8976-C252-11
275
6.3.6
Commands in the MSTP configuration mode
This section describes commands that you can call up in the MSTP configuration mode.
In the Global configuration mode, enter the
spanning-tree mst configuration command to
change to this mode.
● If you exit the MSTP configuration mode with the
exit command, you return to the Global
configuration mode.
● If you exit the MSTP configuration mode with the
end command, you return to the
Privileged EXEC mode.
6.3.6.1
instance
Description
With this command, you assign a range of VLANs to an MST instance.
Requirement
You are in the MSTP configuration mode.
The command prompt is as follows:
cli(config-mst)#
Syntax
Call up the command with the following parameters:
instance <instance-id(1-64)> vlan <vlan-range>
The parameters have the following meaning:
Parameter
Description
Range of values / note
instance-id
Number of the instance 1 ... 64
You can define up to 16 MSTP
instances.
Default:
The VLANs 1 – 4094 are as-
signed to instance "0"
vlan
Keyword for a VLAN connection -
vlan-range
Range of VLANs assigned to an in-
stance
enter the range limts with a hy-
phen or blank
Result
The range of VLANs is assigned to the MST instance.
