Siemens SCALANCE XM-400 Configuration Manual

Layer 3 functions
9.2 OSPFv2 (IPv4)
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 06/2016, C79000-G8976-C252-11
515
The parameters have the following meaning:
Parameter
Description
Range of values / note
area-id
Area-ID specify an ID.
x.x.x.x
x = 0 ... 255
0.0.0.0 = backbone area.
asbr-summary
only shows information of the LSA type
ASPR (Autonomous System Border
Router). (Type 4)
-
external
only shows information of the LSA type
"External" (Type 5)
-
network
only shows information of the LSA type
"Network" (Type 2)
-
nssa-external
only shows information of the LSA type
"NSSA (Not so stubby area) External"
(Type 7)
-
router
only shows information of the LSA type
"Router" (Type 1)
-
summary
only shows information of the LSA type
"Summary" (Type 3)
-
link-state-id
ID of the LSA .
Link State ID depends on the LSA
type.
Link State ID consists of 4 num-
bers each between 0 and 255
adv-router
Keyword for the router-specific LSA
-
ip-address
shows the router-specific LSA for a
specific IP address
specify a valid IP address.
If no IP address is entered, the
specific LSAs of the local router
are displayed.
self-originate
Number of LSAs generated by the local
router
-
For information on names of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 42)".
Result
The information on the selected LSA type is displayed.
9.2.1.5
show ip ospf border-routers
Description
This command shows the routes to the area border routers and to the AS boundary routers.
Requirement
You are in the User EXEC mode or in the Privileged EXEC mode.
The command prompt is as follows:
cli> or cli#
