Security and authentication
11.4 IP access control list
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 06/2016, C79000-G8976-C252-11
837
11.4.3.1
ip access-group
Description
With this command, you enable the access control of the packets of an interface.
Note
In the internal configuration mode of a VLAN, the ACL rule applies to all ports that belong to
the VLAN.
Requirement
● An IP access list has been created.
● You are in the Interface Configuration mode of a switch port, a router port or a VLAN.
The command prompt is as follows:
– With a switch port:
cli(config-if-Gi$-$)#
cli(config-if-Ex$-$)#
– With a router port
cli(config-RPort-Gi$-$)#
– With a VLAN
cli(config-if-vlan-$$$)#
Syntax
Call up the command with the following parameters:
ip access-group <access-list-number(1-128)> {in|out}
The parameters have the following meaning:
Parameter
Description
Range of values / note
access-list-number
Number of the access control list
1 ... 128
in
Specifies that incoming packets are
filtered
-
out
Specifies that outgoing packets are
filtered
-
Note
Restrictions when filtering layer 2 interfaces
Use an expanded MAC address access co
ntrol list to filter packets outgoing on layer 2
interfaces.
