Configuration
3.1 System
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
86 Configuration Manual, 06/2016, C79000-G8976-C252-11
EtherNet/IP is enabled or disabled after the next restart.
You can display the current EtherNet/IP configuration with the show ethernetip command.
You restore the default settings of the EtherNet/IP profile with the
restart command.
With this command, you change to the Interface configuration mode.
There you can edit the settings for one interface. You select the interface with the
parameters of this command. If you specify a logical interface that does not exist, it will be
created. The name of the selected interface is displayed in the command prompt.
You are in the Global configuration mode.
The command prompt is as follows:
cli(config)#
Call up the command with the following parameters:
interface{cpu0|vlan<vlan
-id(1
-4094)>|port
-channel<port
-channel
-id(1
-8)>|
<interface-type><interface-id>}
The parameters have the following meaning:
The configuration mode for the "Out of
Band Management interface" is called
-
Keyword for a VLAN connection -
Number of the addressed VLAN
Keyword for a port channel connection
Number of the addressed port channel
Type or speed of the interface
Enter a valid interface.
Module no. and port no. of the interface
For information on names of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 42)".
