Layer 3 functions
9.2 OSPFv2 (IPv4)
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 06/2016, C79000-G8976-C252-11
531
The parameters have the following meaning:
Area-ID enter a valid ID.
x.x.x.x
x = 0 ... 255
The area ID 0.0.0.0 is reserved for the backbone area
The area is removed or changed.
area virtual-link
Description
With this command, you create a virtual connection to the backbone area.
Note
This command is available only with layer 3. The router must be an Area Border Router
(ABR) or an Autonomous System Boundary Router (ASBR). The router ID must correspond
to the IP address of the interf
ace of the transit area network.
You are in the OSPF Router configuration mode.
The command prompt is as follows:
cli(config-ospf)#
Call up the command with the following parameters:
area <area-id> virtual-link <router-id>
[authentication
{
simple |messagedigest| null
}
]
[hello-interval <value (1-65535)>]
[retransmit-interval <value(0-3600)>]
[transmit-delay <value (0-3600)>]
[dead-interval <value>]
