Siemens SCALANCE XM-400 Configuration Manual

Diagnostics
12.1 Event and fault handling
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
892 Configuration Manual, 06/2016, C79000-G8976-C252-11
Further notes
You exit the EVENTS configuration mode with the command end or exit.
12.1.5.2
cabletest interface
Description
With this command, you enable the cable test for the specified interface.
Note
Wire pairs
Wire pairs 4
-5 and 7-8 of 10/100 Mbps network cables are not used.
The wire pair assignment
- pin assignment is as follows (DIN 50173):
Pair 1 = pin 1
-2
Pair 2 = pin 3
-6
Pair 3 = pin 4
-5
Pair 4 = pin 7
-8
Requirement
● The interface has no active data traffic.
● You are in the Global configuration mode.
The command prompt is:
cli(config)#
Syntax
Call up the command without parameters or with the following parameter assignment:
cabletest interface <interface-type> <interface-id> [force]
The parameters have the following meaning:
Parameter
Description
Range of values / note
interface-type
Type of interface
Enter a valid interface.
interface-id
Interface identifier
force
Forces a link down during the test Necessary parameter if there is a
link up on the interface.
For information on names of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 42)".
If you do not select any parameters from the parameter list, the default value is used.
