Network structures
6.1 VLAN
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
198 Configuration Manual, 06/2016, C79000-G8976-C252-11
With this command, you delete a VLAN on the device.
● The VLAN must not be assigned to a physical port.
● You are in the Global Configuration mode.
The command prompt is as follows:
cli(config)#
Call up the command with the following parameter:
no vlan <vlan-id(1-4094)>
Number of the addressed VLAN
The VLAN with number 1 cannot be deleted.
The VLAN is deleted
With the vlan command, you create a VLAN on the device.
You can display information about the VLAN with the
show vlan command.
With this command, you can select several VLANs and configure them together. The
configurations are valid for all selected VLANs.
You are in the Global configuration mode.
The command prompt is as follows:
cli(config)#
