Network protocols
7.1 IPv4 protocol
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 06/2016, C79000-G8976-C252-11
305
You configure the static IPv4 address with the ip address command.
You display this setting and other information with the
show ip interface command.
You enable DHCP with the
ip address dhcp command.
dcp forwarding
Description
With this command, you configure the forwarding behavior of the interface for DCP frames.
Note
PROFINET configuration
Since DCP is a PROFINET protocol, the configuration created here is only effective with the
VLAN associated with the TIA interface.
You are in the Interface configuration mode.
The command prompt is as follows:
cli(config-if-$$$)#
Call up the command with the following parameters:
dcp forwarding {block|forward}
The parameters have the following meaning:
The forwarding behavior of the interface for DCP frames is configured.
