Diagnostics
12.4 Port Mirroring
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 06/2016, C79000-G8976-C252-11
929
Further notes
You delete the destination for mirroring a port with the no monitor session ... destination
command.
You end and delete a session with the
no monitor session command.
You display the configuration settings with the
show monitor session command.
12.4.2.6
no monitor session destination
Description
With this command, you delete the destination for mirroring a port.
Requirement
You are in the Global configuration mode.
The command prompt is as follows:
cli(config)#
Syntax
Call up the command with the following parameters:
no monitor session <session-id(1-7)> destination
{interface <interface-type><interface-id>} | remote vlan <vlan-id (1-4094)>}
The parameters have the following meaning:
Parameter
Description
Range of values / note
session-id
Number of the session
7 parallel sessions are possible
only with port-based mirroring and
their ports must not overlap.
1 ... 7
interface
Keyword for a an interface descrip-
tion
-
interface-type
Type or speed of the interface
Enter a valid interface.
If you connect a BANY Agent XM-400 with a SCALANCE
XM-400 basic device as of firmware version 5.1, you can
select up to four ports of the BANY Agent XM-400 as desti-
nation ports. The BANY Agent XM-400 supports port-based
and VLAN-based mirroring.
interface-id
Module no. and port no. of the
interface
remote vlan
Keyword for a RSPAN session
-
vlan-id
Number of the VLAN for the
RSPAN session
1 ... 4094
For information on names of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 42)".
