Layer 3 functions
9.4 VRRPv2 (IPv4)
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
618 Configuration Manual, 06/2016, C79000-G8976-C252-11
The parameters have the following meaning:
Parameter
Description
Range of values / note
vlan
Keyword for a VLAN connection
-
vlan-id
Number of the addressed VLAN 1 ... 4094
VrId
ID of the virtual router
1 ... 255
brief
shows brief information on VRRP
-
detail
shows detailed information on VRRP.
-
statistics
shows the statistics of the VRRP pro-
tocol
-
For information on names of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 42)".
Result
The settings of the virtual router are displayed.
9.4.1.2
show vrrp interface
Description
This command shows the settings of VRRP for the interface.
Requirement
You are in the User EXEC mode or in the Privileged EXEC mode.
The command prompt is as follows:
cli> or cli#
Syntax
Call up the command with the following parameters:
show vrrp interface [vlan <vlan-id(1-4094)>] [{brief|detail|statistics}]
The parameters have the following meaning:
Parameter
Description
Range of values / note
vlan
Keyword for a VLAN connection
-
vlan-id
Number of the addressed VLAN
1 ... 4094
brief
shows brief information on VRRP
-
detail
shows detailed information on VRRP.
-
statistics
shows the statistics of the VRRP pro-
tocol
-
For information on names of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 42)".
