Layer 3 functions
9.10 PIM (IPv4)
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 06/2016, C79000-G8976-C252-11
767
The parameters have the following meaning:
Parameter
Description
Range of values / note
Group Address
Address of the multicast group
-
Group Mask
Subnet mask that restricts the multicast
band
-
RP address
IP address of the interface
-
Result
The interface is not a candidate for the rendezvous point.
Further notes
You define interface candidates for the rendezvous point (RP) with the rp-candidate rp-
address
command.
You display the interface candidates for rendezvous points with the
show ip pim rp-
candidate
command.
9.10.4.3
rp-static rp-address
Description
With this command you specify which interfaces will become static rendezvous points.
Configure the static RP on all devices of the PIM component.
Requirement
You are in the PIM configuration mode.
The command prompt is as follows:
cli(router-pim)#
Syntax
Call up the command with the following parameters:
rp-static rp-address <Group Address> <Group Mask> <IP address>
