Siemens SCALANCE XM-400 Configuration Manual

Description
2.3 Configuration limits
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
38 Configuration Manual, 06/2016, C79000-G8976-C252-11
Configurable function
Maximum number
NAT interfaces
5
VRRP router interfaces (only VLAN interfaces) 52
OSPF areas per device
5
OSPFv2 area range entries per OSPF area (intra-area sum-
mary)
3
OSPFv3 area range entries per OSPF area (intra-area sum-
mary)
10
OSPF interfaces
40
OSPF interfaces per OSPF area
40
OSPF virtual links (within an autonomous system)
8
OSPFv3 neighbors
300
OSPFv3 neighbors per interface
8
OSPFv3 routes
1500
OSPFv2 interfaces authentication keysl 200
(40 interfaces each with 5
keys)
OSPFv2 virtual links authentication keys 40
(8 virtual links each with
5 keys)
PIM components
1
Rendezvous points 3
Candidates for rendezvous points
3
Static rendezvous points
3
Security
Roles
29
Users 30
(incl. user preset in the
factory "admin")
Groups
32
RADIUS Server
4
Management ACLs (access rules for management)
10
Rules for port ACL MAC
128
Ingress and egress rules for port ACL MAC (total)
364
Rules for port ACL IP
128
Ingress and egress rules for port ACL IP (total)
364
Rules for VLAN ACL IP
128
