Description
2.6 Interface identifiers and addresses
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 06/2016, C79000-G8976-C252-11
43
Note
If you use an M
M900 media module with an optical interface, use gigabitethernet for the
interface
-type parameter. For further information on the media modules, refer to the
compact operating instructions of the MM900 media modules for SCALANCE XR
-500.
Available interface identifiers with SCALANCE XM-400
● Interfaces of the basic device
The interfaces of the basic device SCALANCE XM-400 are called module 1.
● Interfaces of extenders
The port extenders are called module 2 and module 3 starting from the basic device. The
number of port extenders depends on the number of ports of the basic device.
Function extenders are module 0.
Available interface identifiers with SCALANCE XR-500
● Fixed interfaces
The interfaces permanently installed in the SCALANCE XR-500 are identified with
module 0.
cpu0: Out of band interface
● Interfaces of modules
The slots for modules are called module 1 and the following numbers. The numbering
range depends on the hardware configuration. The numbering is fixed and does not
depend on the number of modules being used.
Each module has 4 ports numbered 1 to 4.
Available logical interfaces
● VLAN
The device supports up to 127 VLAN ports.
To be able to use a VLAN, create it with the
vlan command.
● Aggregated links, aggregated ports, port channel, Etherchannel
These terms are used for the same function:
Several ports or connections between two devices are logically bundled together
(aggregated) to achieve a higher data transmission rate and a lower failure risk.
The device supports 8 link aggregations or Etherchannels each with a maximum of 8
ports per aggregation.
To add an interface to an Etherchannel, use the "
channel-group" command.
