Layer 3 functions
9.4 VRRPv2 (IPv4)
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
624 Configuration Manual, 06/2016, C79000-G8976-C252-11
Requirement
You are in the VRRP Router configuration mode.
The command prompt is as follows:
cli(config-vrrp)#
Syntax
Call up the command with the following parameters:
track <group-index> interface { vlan <vlan-id (1-4094)> | <interface-type>
<interface-id> }
The parameters have the following meaning:
Parameter
Description
Range of values / note
group-index
ID of the interface tracking
-
vlan
Keyword for a VLAN connection -
vlan-id
Number of the addressed VLAN
1 … 4094
interface-type
Type of interface Specify a valid interface.
interface-id
Module no. and port no. of the interface
For information on names of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 42)".
Result
The selected interface is monitored.
Further notes
You delete an interface tracking with the no interface interface command.
You display the configured interface tracking with the
show vrrp track command.
You assign a VRRP interface to an interface tracking with the
vrrp track decrement
command.
You configure the value by which the priority is reduced with the command
vrrp track
decrement
.
With the
track links command you configure how many of the monitored interfaces need to
change their status before the priority of the assigned VRRP interface is changed.
