Security and authentication
11.4 IP access control list
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 06/2016, C79000-G8976-C252-11
849
You have the following options:
● All incoming and/or outgoing TCP segments are not forwarded.
● Incoming and/or outgoing TCP segments of a specific host are not forwarded.
● Incoming and/or outgoing TCP segments of hosts of a specific subnet are not forwarded.
● Incoming and/or outgoing TCP segments are not forwarded to specific ports.
Note
Processing order of the lists
The access control lists are processed on the interface i
n the order in which they were
The index number of the access control list is not used for this.
You are in the ACL standard configuration mode.
The command prompt is as follows:
cli(config-std-nacl)#
Call up the command with the following parameters:
deny tcp {any | host <src-ip-address> | <src-ip-address> <src-mask>} [{ gt <src-port-
number(1-65535)> | lt <src-port-number(1-65535)> | eq src-port-number(1-65535)> |
range <src-port-number (1-65535)> <src-port-number (1-65535)>}] [{any | host <dest-
ip
-address> | <dest-ip
-address> <dest-mask>}] [{ gt <port
-number(1
-65535)> | lt <port-number(1-65535)> | eq <port-number(1-65535)> | range <port-number (1-65535)>
<port-number (1-65535)>}] [dscp<value(0-63)>] [{ack | rst}]
The parameters have the following meaning:
Blocks all incoming TCP segments
Keyword for a an individual IPv4 ad-
-
Enter a valid IPv4 address.
Enter a valid combination of IPv4
address and subnet mask.
Corresponding subnet mask
Keyword for port numbers higher than
the specified number (gt: greater than).
-
Keyword for port numbers lower than
the specified number (lt: less than).
-
