set port mirroring
11-40 Port Configuration
Defaults
None.
Mode
Switch command, read-only.
Example
This example shows how to display port mirroring information. In this case, ge.1.4 is configured
as a source port and ge.1.11 is a target and mirroring has been enabled between these ports:
C3(su)->show port mirroring
Port Mirroring
==============
Source Port =
ge.1.4
Target Port =
ge.1.11
Frames Mirrored = Rx and Tx
Port Mirroring status enabled.
set port mirroring
Use this command to create a new mirroring relationship or to enable or disable an existing
mirroring relationship between two ports.
Syntax
set port mirroring {create | disable | enable} source destination}
Parameters
Defaults
Port mirrors are automatically enabled when created on this platform.
Mode
Switch command, read-write.
Notes: When a port mirror is created, the mirror destination port is removed from VLAN 1’s egress
list after a reboot.
"MAC addresses will be learned for packets tagged with the mirror VLAN ID. This will prevent the
ability to snoop traffic across multiple hops.
create | disable |
enable
Creates, disables or enables mirroring settings on the specified ports. By
default, port mirrors are enabled automatically when created.
source Specifies the source port designation. This is the port on which the traffic
will be monitored. Up to 8 source ports can be specified. For a detailed
description of possible port-string values, refer to “Port String Syntax Used
in the CLI” on page 11-1.
destination Specifies the target port designation. This is the port that will duplicate or
“mirror” all the traffic on the monitored port. Only one destination port
can be configured per stack, if applicable.
For a detailed description of possible port-string values, refer to “Port
String Syntax Used in the CLI” on page 11-1.
