show mac
18-10 Network Management
Defaults
If not specified, waittime will be set to 5 seconds.
If not specified, first-ttl will be set to 1 second.
If not specified, max-ttl will be set to 30 seconds.
If not specified, port will be set to 33434.
If not specified, nqueries will be set to 3.
If -r is not specified, normal host routing tables will be used.
If -d is not specified, the debug socket option will not be used.
If -v is not specified, summary output will be displayed.
Mode
Switch command, read-only.
Example
This example shows how to use traceroute to display a round trip path to host 192.167.252.17. In
this case, hop 1 is the Enterasys C3 switch, hop 2 is 14.1.0.45, and hop 3 is back to the host IP
address. Round trip times for each of the three UDP probes are displayed next to each hop:
C3(su)->traceroute 192.167.252.17
traceroute to 192.167.252.17 (192.167.252.17), 30 hops max, 40 byte packets
1 matrix.enterasys.com (192.167.201.40) 20.000 ms 20.000 ms 20.000 ms
2 14.1.0.45 (14.1.0.45) 40.000 ms 10.000 ms 20.000 ms
3 192.167.252.17 (192.167.252.17) 50.000 ms 0.000 ms 20.000 ms
show mac
Use this command to display MAC addresses in the switch’s filtering database. These are
addresses learned on a port through the switching process.
Syntax
show mac [address mac-address] [fid fid] [port port-string] [type {other | learned
| self | mgmt | mcast}]
Parameters
-v (Optional) Displays verbose output, including the size and destination of
each response.
host Specifies the host to which the route of an IP packet will be traced.
address mac-address (Optional) Displays a specific MAC address (if it is known by the
device).
fid
fid (Optional) Displays MAC addresses for a specific filter database
identifier.
port port-string (Optional) Displays MAC addresses for specific port(s).
type other |learned |
self | mgmt | mcast
(Optional) Displays information related to other, learned, self, mgmt
(management), or static multicast (mcast) address type.
