TC1796
System Units (Vol. 1 of 2)
System Control Unit
User’s Manual 5-62 V2.0, 2007-07
SCU, V2.0
OSC_CON Oscillator Control Register 18
H
Page 3-8
WDT_CON0 Watchdog Timer Control Register 0 20
H
Page 16-29
WDT_CON1 Watchdog Timer Control Register 1 24
H
Page 16-31
WDT_SR Watchdog Timer Status Register 28
H
Page 16-32
NMISR NMI Status Register 2C
H
Page 14-27
PMG_CSR Power Management Control and Status
Register
34
H
Page 5-4
SCU_SCLIR SCU Software Configuration Latched
Inputs Register
38
H
Page 10-24
PLL_CLC PLL Clock Control Register 40
H
Page 3-16
SCU_EMSR SCU Emergency Stop Register 44
H
Page 5-59
SCU_TCCON SCU Temperature Compensation Control
Register
48
H
Page 5-44
SCU_CON SCU Control Register 50
H
Page 5-64
SCU_STAT SCU Status Register 54
H
Page 5-67
SCU_TCLR0 SCU Temperature Compensation 0 Level
Register
58
H
Page 5-46
SCU_TCLR1 SCU Temperature Compensation 1 Level
Register
5C
H
Page 5-47
MANID Manufacturer Identification Register 70
H
Page 5-69
CHIPID Chip Identification Register 74
H
Page 5-70
RTID Redesign Tracing Identification Register 78
H
Page 5-71
EICR0 External Input Channel Register 0 80
H
Page 5-17
EICR1 External Input Channel Register 1 84
H
Page 5-20
EIFR External Input Flag Register 88
H
Page 5-23
FMR Flag Modification Register 8C
H
Page 5-24
PDRR Pattern Detection Result Register 90
H
Page 5-25
IGCR0 Interrupt Gating Register 0 94
H
Page 5-26
IGCR1 Interrupt Gating Register 1 98
H
Page 5-29
TGADC0 Trigger Gating ADC0 Register 9C
H
Page 5-32
TGADC1 Trigger Gating ADC1 Register A0
H
Page 5-32
Table 5-9 SCU Registers (cont’d)
Register Short
Name
Register Long Name Offset
Address
Description
