Control Registers
1535
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Multi-Buffered Serial Peripheral Interface Module (MibSPI) with Parallel Pin
Option (MibSPIP)
28.3 Control Registers
This section describes the SPI control, data, and pin registers. The registers support 8-bit, 16-bit and 32-
bit writes. The offset is relative to the associated base address of this module in a system. The base
address for the control registers is FFF7 F400h for MibSPI1, FFF7 F600h for MibSPI2, FFF7 F800h for
MibSPI3, FFF7 FA00h for MibSPI4, and FFF7 FC00h for MibSPI5.
NOTE: TI highly recommends that write values corresponding to the reserved locations of registers
be maintained as 0 consistently. This allows future enhancements to use these reserved bits
as control bits without affecting the functionality of the module with any older versions of
software.
(1)
SPIPC9 only applies to SPI2.
Table 28-8. SPI Registers
Offset Acronym Register Description Section
00h SPIGCR0 SPI Global Control Register 0 Section 28.3.1
04h SPIGCR1 SPI Global Control Register 1 Section 28.3.2
08h SPIINT0 SPI Interrupt Register Section 28.3.3
0Ch SPILVL SPI Interrupt Level Register Section 28.3.4
10h SPIFLG SPI Flag Register Section 28.3.5
14h SPIPC0 SPI Pin Control Register 0 Section 28.3.6
18h SPIPC1 SPI Pin Control Register 1 Section 28.3.7
1Ch SPIPC2 SPI Pin Control Register 2 Section 28.3.8
20h SPIPC3 SPI Pin Control Register 3 Section 28.3.9
24h SPIPC4 SPI Pin Control Register 4 Section 28.3.10
28h SPIPC5 SPI Pin Control Register 5 Section 28.3.11
2Ch SPIPC6 SPI Pin Control Register 6 Section 28.3.12
30h SPIPC7 SPI Pin Control Register 7 Section 28.3.13
34h SPIPC8 SPI Pin Control Register 8 Section 28.3.14
38h SPIDAT0 SPI Transmit Data Register 0 Section 28.3.15
3Ch SPIDAT1 SPI Transmit Data Register 1 Section 28.3.16
40h SPIBUF SPI Receive Buffer Register Section 28.3.17
44h SPIEMU SPI Emulation Register Section 28.3.18
48h SPIDELAY SPI Delay Register Section 28.3.19
4Ch SPIDEF SPI Default Chip Select Register Section 28.3.20
50h-5Ch SPIFMT0-SPIFMT3 SPI Data Format Registers Section 28.3.21
60h INTVECT0 Interrupt Vector 0 Section 28.3.22
64h INTVECT1 Interrupt Vector 1 Section 28.3.23
68h SPIPC9
(1)
SPI Pin Control Register 9 Section 28.3.24
6Ch SPIPMCTRL Parallel/Modulo Mode Control Register Section 28.3.25
70h MIBSPIE Multi-buffer Mode Enable Register Section 28.3.26
74h TGITENST TG Interrupt Enable Set Register Section 28.3.27
78h TGITENCR TG Interrupt Enable Clear Register Section 28.3.28
7Ch TGITLVST Transfer Group Interrupt Level Set Register Section 28.3.29
80h TGITLVCR Transfer Group Interrupt Level Clear Register Section 28.3.30
84h TGINTFLG Transfer Group Interrupt Flag Register Section 28.3.31
90h TICKCNT Tick Count Register Section 28.3.32
94h LTGPEND Last TG End Pointer Section 28.3.33
98h-D4h TGxCTRL TGx Control Registers Section 28.3.34
D8h-F4h DMAxCTRL DMA Channel Control Registers Section 28.3.35
F8h-114h ICOUNT DMAxCOUNT Registers Section 28.3.36
