EMAC/MDIO Module
17.3.3.11 MAC Input Vector Register (MACINVECTOR)
The MAC input vector register (MACINVECTOR) is shown in Figure 17-49 and described in Table 17-48.
Figure 17-49. MAC Input Vector Register (MACINVECTOR)
31 28 27 26 25 24 23 16
Reserved STATPEND HOSTPEND LINKINT0 USERINT0 TXPEND
R-0 R-0 R-0 R-0 R-0 R-0
15 8 7 0
RXTHRESHPEND RXPEND
R-0 R-0
LEGEND: R = Read only; -n = value after reset
Table 17-48. MAC Input Vector Register (MACINVECTOR) Field Descriptions
Bit Field Value Description
31-28 Reserved 0 Reserved
27 STATPEND 0-1 EMAC module statistics interrupt (STATPEND) pending status bit
26 HOSTPEND 0-1 EMAC module host error interrupt (HOSTPEND) pending status bit
25 LINKINT0 0-1 MDIO module USERPHYSEL0 (LINKINT0) status bit
24 USERINT0 0-1 MDIO module USERACCESS0 (USERINT0) status bit
23-16 TXPEND 0-FFh Transmit channels 0-7 interrupt (TXnPEND) pending status. Bit 16 is TX0PEND.
15-8 RXTHRESHPEND 0-FFh Receive channels 0-7 interrupt (RXnTHRESHPEND) pending status. Bit 8 is
RX0THRESHPEND.
7-0 RXPEND 0-FFh Receive channels 0-7 interrupt (RXnPEND) pending status bit. Bit 0 is RX0PEND.
