EMAC/MDIO Module
17.3.3.4 Receive Revision ID Register (RXREVID)
The receive revision ID register (RXREVID) is shown in Figure 17-42 and described in Table 17-41.
Figure 17-42. Receive Revision ID Register (RXREVID)
31 0
RXREV
R-4EC0 020Dh
LEGEND: R = Read only; -n = value after reset
Table 17-41. Receive Revision ID Register (RXREVID) Field Descriptions
Bit Field Value Description
31-0 RXREV Receive module revision
4EC0 020Dh Current receive revision value
17.3.3.5 Receive Control Register (RXCONTROL)
The receive control register (RXCONTROL) is shown in Figure 17-43 and described in Table 17-42.
Figure 17-43. Receive Control Register (RXCONTROL)
31 16
Reserved
R-0
15 1 0
Reserved RXEN
R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 17-42. Receive Control Register (RXCONTROL) Field Descriptions
Bit Field Value Description
31-1 Reserved 0 Reserved
0 RXEN Receive enable
0 Receive is disabled.
1 Receive is enabled.
